Enabling the Clipping Plane in 2D View

Once you have set clipping planes using the Set Clipping Plane tool , you can view the clipped results within the map.

How to Enable the Clipping Plane in 2D View

1. If you have not already done so, set the clipping planes to view within the map window.

2. Click the Enable Clipping Plane in 2D View tool (LP360 Standalone) on the Viewer Integration toolbar.

3. If the button is pressed, the clipped results will display within the map window.
